MC GHEE TYSON (TYS)(KTYS) P (ANG ARNG) 10 S UTC–5(–4DT) N35°48.67′ W83°59.64′
986 B LRA Class I, ARFF Index C NOTAM FILE TYS
RWY 05L–23R: H10000X150 (CONC–GRVD) S–120, D–250, 2D–550, 2D/2D2–1120 PCR 761 R/B/W/T HIRL CL
RWY 05L: MALSR. PAPI(P4L)—GA 3.0° TCH 55′. RVR–TMR Thld dsplcd 490′. 0.8% up.
RWY 23R: ALSF2. TDZL. PAPI(P4L)—GA 3.0° TCH 56′. RVR–TMR Thld dsplcd 505′. Rgt tfc. 0.4% down.
RWY 05R–23L: H9000X150 (ASPH–GRVD) S–75, D–250, 2D–489, 2D/2D2–1106 PCR 492 F/B/X/U HIRL CL
RWY 05R: TDZL. REIL. PAPI(P4L)—GA 3.0° TCH 50′. RVR–R Rgt tfc. 0.5% up.
RWY 23L: REIL. PAPI(P4L)—GA 3.0° TCH 50′. RVR–T Thld dsplcd 397′.
RUNWAY DECLARED DISTANCE INFORMATION
RWY 05L:TORA–10000 TODA–10000 ASDA–10000 LDA–9508
RWY 05R:TORA–9000 TODA–9000 ASDA–8600 LDA–8600
RWY 23L:TORA–9000 TODA–9000 ASDA–9000 LDA–8600
RWY 23R:TORA–10000TODA–10000 ASDA–10000 LDA–9495
SERVICE: S4 FUEL 100LL, JET A, A++ OX 1 MILITARY— JASU (A/M32A–86) (A/M32A–95) FUEL A++(Mil), A, A+ (C865–970–3049.) (100LL) Mil contr fuel avbl. FLUID PRESAIR LPOX OIL O–148(Mil)
AIRPORT REMARKS: Attended continuously. Birds on and invof arpt, incrd Oct–Apr. Rscd not mntd 2130–1300Z‡ dly, wkend and hol. CTN: Ptn of Twy A near Rwy 05R apch end not vsb fm twr. CTN: Hold short line for Rwy 23L slightly N of Twy A–8. Rwy 05L–23R and Rwy 05R–23L wt brg cpty for 2S lndg gear is 175. Rwy 23L, Rwy 23R dep mntn rwy hdg until passing residential area S of extdd cntrln unless instrd by ATC. Wide body use ctn turning onto Twy A fm Ramp 4, 5 and 6.
MILITARY REMARKS: CSTMS/AG/IMG Mil customs 72 hr PPR. ANG PPR 24 hr PPR; ltd to offl bus only—Amgmt D266–4404/4419|C865–336–4404/4419. ANG Ops ctc SODA Ctl 303.025. COMD POST opr H24—DSN 266–4371, C865–336–4371. Amgr does not issue or store COMSEC for tsnt. Tmpry stor of classified materials up to TOP SECRET at Comd Post. ARNG ramp not suitable for AMC acft exc C–21. Civil PPR to use Twys G1; G2; G3 & G south of Twy G—ANG 865–336–4371. ARMY NG ANG base ops 1230–2200Z‡ Mon–Fri. PPR—D266–4601/4605.
AIRPORT MANAGER: 865-342-3088
WEATHER DATA SOURCES: ASOS (865) 981–4053 LLWAS. WSP.
COMMUNICATIONS: ATIS 128.35 UNICOM 122.95
RCO 122.2 (NASHVILLE RADIO)
®KNOXVILLE APP/DEP CON 118.0 (051°–229°) 123.9 (230°–050°)
KNOXVILLE TOWER 121.2 GND CON 121.9 KNOXVILLE CLNC DEL 121.65
ANG OPS 303.025 (Call SODA Ctl) ARNG OPS 49.95 149.8 373.9
AIRSPACE: CLASS C svc ctc APP CON.
VOR TEST FACILITY (VOT) 112.0
RADIO AIDS TO NAVIGATION: NOTAM FILE TYS.
VOLUNTEER (H) (H) VORTACW 116.4 VXV Chan 111 N35°54.29′ W83°53.68′ 224° 7.4 NM to fld. 1315/3W.
ILS 110.3 I–TYS Rwy 05L. Class IE. LOC unusable byd 30° right of course.
ILS/DME 110.75 I–OXH Chan 44(Y) Rwy 23L. Class IE. LOC unusable inside 7.2 DME above 5,300 MSL to 2,000 MSL at 1.6 DME.
ILS 111.7 I–BUI Rwy 23R. Classification code IIE.
