EUGENE F KRANZ TOLEDO EXPRESS (TOL)(KTOL) P (ANG) 10 SW UTC–5(–4DT) N41°35.21′
W83°48.47′ 684 B LRA ARFF Index—See Remarks NOTAM FILE TOL
RWY 07–25: H10600X150 (ASPH–GRVD) S–100, D–174, 2S–175, 2D–300, 2D/2D2–550 PCN 67 F/B/W/T HIRL CL
RWY 07: ALSF2. TDZL. RVR–TR Trees.
RWY 25: MALSR. PAPI(P4L)—GA 3.0° TCH 69′. RVR–TR Trees. 0.3% up.
RWY 16–34: H5599X150 (ASPH–GRVD) S–100, D–174, 2S–175, 2D–300 PCN 52 F/B/W/T MIRL
RWY 16: REIL. PAPI(P4L)—GA 3.0° TCH 48′. Trees.
RWY 34: REIL. PAPI(P4L)—GA 3.0° TCH 50′.
RUNWAY DECLARED DISTANCE INFORMATION
RWY 07: TORA–10599 TODA–10599 ASDA–10599 LDA–10599
RWY 16: TORA–5599 TODA–5599 ASDA–5599 LDA–5599
RWY 25: TORA–10599 TODA–10599 ASDA–10599 LDA–10599
RWY 34: TORA–5599 TODA–5599 ASDA–5599 LDA–5599
ARRESTING GEAR/SYSTEM
RWY 07 BAK–14 BAK–12B(B) (1500 FT). BAK–14 BAK–12B(B) (1050 FT). RWY 25
SERVICE: S4 FUEL 100LL, JET A, A++ OX 3 LGT SS–SR. Rwy 25 PAPI unusbl byd 8 degs right of cntrln. MILITARY—FUEL: A++(MIL)
AIRPORT REMARKS: Attended continuously. Birds on and invof arpt. Fuel and svc avbl 1300–0500Z‡. Class I, ARFF Index B. 48 hr PPR for unsked acr ops gtr than 10 pax seats — call amgr. Twy N3 & ramp btn Twy B9 & B13 not vsb fm tower. Cust: Sat–Sun req must be made bfr 2200Z‡ Fri — call 419–732–4446.
MILITARY REMARKS: ANG Afld OPS duty hrs 1145–2230Z‡ Mon–Thu, ocnl wkends, excldg hols. PPR— offl bus, acft with wingspans gtr than 75 ft can exp prkg on Twy D or the south cargo ramp, ctc airfield ops DSN 580–4084/4036, C800–495–4250 extn 868–4084/868–4036 or 180.FW.Airfield.Management@US.AF.MIL. 180th Command Post H24 DSN 580–4035. All inbd tsnt acft ctc Command Post. Twy D int Twy D1, hvy acft use mnm pwr to rdc FOD on ANG ramp; for qns ctc Command Post or Airfield Ops on 338.15. Bird haz wildlife act durg migration; BASH Phase II in eff Mar–May & Aug–Oct. Nstd black/yellow eqpt tool box lctn painted on ANG Ramp. Airfield mgmt does not issue/store comsec; for comsec storage ctc Command Post DSN 580–4035.
AIRPORT MANAGER: 567-703-8631
WEATHER DATA SOURCES: ASOS (419) 865–6924 WSP.
COMMUNICATIONS: ATIS 118.75 UNICOM 122.95
®APP/DEP CON 126.1 (360°–179°) 134.35 (180°–359°) 123.975
TOWER 118.1 GND CON 121.9 CLNC DEL 121.75
AIRSPACE: CLASS C svc ctc APP CON.
RADIO AIDS TO NAVIGATION: NOTAM FILE TOL.
TOPHR NDB (LOMW) 219 TO N41°33.21′ W83°55.27′ 074° 5.5 NM to fld. 676/5W. NDB unmonitored.
ILS 109.7 I–TOL Rwy 07. Class IE. LOM TOPHR NDB. LOM unmonitored.
ILS/DME 108.7 I–BQE Chan 24 Rwy 25. Class IE.
ASR
COMM/NAV/WEATHER REMARKS: ATIS reception intmt 270–320 degs, byd 35 NM.
