TALLAHASSEE INTL (TLH)(KTLH) 4 SW UTC–5(–4DT) N30°23.81′ W84°21.05′
83 B Class I, ARFF Index C NOTAM FILE TLH MON Airport
RWY 09–27: H8000X150 (ASPH–GRVD) S–115, D–170, 2D–330 PCN 48 F/A/X/T HIRL CL
RWY 09: REIL. PAPI(P4L)—GA 3.0° TCH 58′. RVR–TR
RWY 27: ALSF2. TDZL. PAPI(P4L)—GA 3.0° TCH 58′. RVR–TR 0.3% up.
RWY 18–36: H7000X150 (ASPH–GRVD) S–115, D–170, 2D–330 PCN 47 F/A/X/T HIRL 0.4% up N
RWY 18: REIL. PAPI(P4L)—GA 3.0° TCH 55′. RVR–R
RWY 36: MALSR. PAPI(P4L)—GA 3.0° TCH 54′. RVR–T
SERVICE: S4 FUEL 100LL, JET A OX 1, 3 LGT When ATCT clsd ACTVT MALSR 36; REIL Rwy 09 and 18; PAPI Rwy 09, 27, 18 and 36; HIRL Rwy 09–27 and 18–36—CTAF. ALSF2 Rwy 27 preset on med intst.
AIRPORT REMARKS: Attended continuously. Birds on and invof arpt. Movement area of Twy Z begins at the int of Twy B8 and proceeds east to the int of Twy B7 this twy is not for use by air carrier ops. Asph btn Twy B8 and Twy A12 is for helicopter ops, Twy Z from Twy A12 to the ramp is open to acft with wingspan of 50′ or less. Longl and transverse cracks prsnt on Rwy 18–36.
AIRPORT MANAGER: 850-891-7802
WEATHER DATA SOURCES: ASOS 119.45 (850) 576–3665. LLWAS.
COMMUNICATIONS: CTAF 118.7 ATIS 119.45 UNICOM 123.075
TALLAHASEE RCO 122.2 (GAINESVILLE RADIO)
SEMINOLE RCO 122.1R 117.5T (GAINESVILLE RADIO)
®APP/DEP CON 128.7 (181°–360°) 135.8 (001°–180°) (1100–0400Z‡)
JACKSONVILLE CENTER APP/DEP CON 128.625 (0400–1100Z‡)
TOWER 118.7 (1100–0400Z‡) GND CON 121.9 CLNC DEL 126.65
CLEARANCE DELIVERY PHONE: For CD if una to ctc on FSS freq, ctc Tallahassee Apch at 850-942-8311, when Apch clsd ctc Jacksonville ARTCC at 904-845-1592.
AIRSPACE: CLASS C svc ctc APP CON svc per TWR/NOTAM 1100–0400Z‡; other times CLASS E.
RADIO AIDS TO NAVIGATION: NOTAM FILE TLH.
SEMINOLE (VH) (H) VORTAC 117.5 SZW Chan 122 N30°33.37′ W84°22.44′ 171° 9.6 NM to fld. 178/2E.
VOR unusable:
006°–034° byd 40 NM
050°–052° byd 40 NM
060°–062° byd 40 NM
065°–068° byd 40 NM
071°–075° byd 40 NM
096°–099° byd 40 NM
103°–107° byd 40 NM
156°–161° byd 40 NM
175°–177° byd 40 NM
180°–190° byd 40 NM blo 18,000′
212°–216° byd 40 NM
220°–223° byd 40 NM
241°–243° byd 40 NM
253°–255° byd 40 NM
261°–270° byd 40 NM
274°–301° byd 40 NM
278°–288° byd 7 NM blo 1,900′
302°–312° byd 40 NM blo 2,000′
302°–312° byd 58 NM
318°–352° byd 40 NM
ILS/DME 111.9 I–PLQ Chan 56 Rwy 27. Class IIE. Unmonitored when ATCT clsd.
ILS/DME 110.3 I–TLH Chan 40 Rwy 36. Class IE.
ASR (1100–0400Z‡)
