PORTLAND INTL JETPORT (PWM)(KPWM) 2 W UTC–5(–4DT) N43°38.74′ W70°18.52′
76 B LRA Class I, ARFF Index C NOTAM FILE PWM MON Airport
RWY 11–29: H7200X150 (ASPH–GRVD) S–75, D–169, 2S–175, 2D–300 PCN 96 F/C/X/T HIRL CL 0.5% up W
RWY 11: ALSF2. TDZL. PAPI(P4R)–GA 3.0° TCH 52′. RVR–TMR Trees.
RWY 29: MALSR. PAPI(P4R)–GA 3.0° TCH 50′. RVR–TMR Tree.
RWY 18–36: H6100X150 (ASPH–GRVD) S–75, D–165, 2D–300 PCN 91 F/C/X/T MIRL
RWY 18: REIL. PAPI(P4L)–GA 3.0° TCH 50′. Thld dsplcd 450′. Tree.
RWY36: REIL. PAPI(P4L)–GA 3.25° TCH 54′. Thld dsplcd 500′. Tree.
LAND AND HOLD–SHORT OPERATIONS
LDG RWY HOLD–SHORT POINT AVBL LDG DIST
RWY 11 18–36 5800
RWY 18 11–29 3100
RUNWAY DECLARED DISTANCE INFORMATION
RWY 11: TORA–7200 TODA–7200 ASDA–7200 LDA–7200
RWY 18: TORA–6100 TODA–6100 ASDA–5600 LDA–5150
RWY 29: TORA–7200 TODA–7200 ASDA–7200 LDA–7200
RWY 36: TORA–6100 TODA–6100 ASDA–5650 LDA–5150
SERVICE: S4 FUEL 100LL, JET A OX 1, 3 LGT Rwy 11 ALSF–II becomes SSALS when ATCT clsd. When twr clsd ACTVT MALSR Rwy 29; REIL Rwy 18 and 36; TDZL Rwy 11; Centerline Rwy 11–29; PAPI Rwy 11, 29, 18 and 36; HIRL Rwy 11–29; MIRL Rwy 18–36–CTAF.
NOISE: For noise abatement info, ctc the arpt ops cntr on freq 129.95 or call 207–756–8310. Prior to any run–up ctc the arpt ops on freq 129.95 or call 207–756–8310. Noise abatement procs in afct for ldg Rwy 11 and dep Rwy 29.
AIRPORT REMARKS: Attended 1100–0300Z‡. Birds ocnly on and invof arpt. For fuel aft hrs call 207–774–6318 or 207–523–0988. Acft emergs btn 0500–1045Z‡ call Portland Air Rescue 207–874–8576. No touch and go ldgs during snow removal. PAEW adj to rwys ngts; gnd vehicles monitor 120.9 when ATCT clsd. Twr occasionally stays open byd 0500Z‡ during adverse wx. Prior to any run–up ctc arpt ops on freq 129.95 or call 207–756–8310. Pushback onto Twy A rqrd fm trml Gates 1–8, Twy C rqrd fm trml Gate 1A. Acft may not push short of Twy A fm Gates 1–8 nor short of Twy C fm Gate 1A. Ctc Gnd 121.9. Adz pushback opr you have Alpha or Charlie prior to push. Landing rights arpt (LRA): GA cust/img fac lctd at cargo apron. Acft arrg/depg cust must use extreme ctn when navigating on the cargo apron to minimize jet blast exposure to hngrs and acft. Flight Notification Svc (ADCUS) avbl.
AIRPORT MANAGER: 207-756-8310
WEATHER DATA SOURCES: ASOS 119.05 (207) 874–7914.
COMMUNICATIONS: CTAF 120.9 ATIS 119.05 (207) 775–1039 UNICOM 122.95
®APP/DEP CON 119.75
®BOSTON CENTER APP/DEP CON 128.2 (0500–1045Z‡)
TOWER 120.9 (1045–0500Z‡) GND CON 121.9
CLNC DEL 121.9
CLEARANCE DELIVERY PHONE: For CD when ATCT clsd, ctc Boston ARTCC at 603-879-6859.
AIRSPACE: CLASS C svc ctc APP CON svc 1045–0500Z‡; other times CLASS E.
VOR TEST FACILITY (VOT) 111.0
RADIO AIDS TO NAVIGATION: NOTAM FILE BGR.
KENNEBUNK (VH) (DH) VORW/DME 117.1 ENE Chan 118 N43°25.54′ W70°36.81′ 062° 18.7 NM to fld. 192/17W.
DME unusable:
030°–184° byd 25 NM blo 2,000′
185°–230° byd 25 NM blo 2,500′
268°–278° byd 30 NM blo 4,600′
VOR unusable:
017°–040° byd 40 NM
130°–133° byd 40 NM
192°–202° byd 40 NM blo 2,500′
192°–202° byd 48 NM blo 5,000′
192°–202° byd 69 NM
203°–294° byd 40 NM
295°–305° byd 40 NM blo 5,000′
295°–305° byd 52 NM
306°–359° byd 40 NM
ILS/DME 109.9 I–PWM Chan 36 Rwy 11. Class IIIE.
ILS/DME 109.9 I–GCS Chan 36 Rwy 29. Class IIE.
