OCALA INTL–JIM TAYLOR FLD (OCF)(KOCF) 4 W UTC–5(–4DT) N29°10.31′ W82°13.45′
90 B ARFF Index—See Remarks NOTAM FILE OCF
RWY 18–36: H7467X150 (ASPH–GRVD) S–111, D–181, 2D–328 PCN 43 F/A/X/T HIRL
RWY 18: PAPI(P4L)—GA 3.0° TCH 45′. Thld dsplcd 160′. Trees.
RWY 36: MALSR. PAPI(P4L)—GA 3.0° TCH 45′. Thld dsplcd 561′. Tree.
RWY 08–26: H3009X50 (ASPH) S–30 PCN 10 F/A/Y/T
RWY 08: Trees.
RWY 26: P–line.
RUNWAY DECLARED DISTANCE INFORMATION
RWY 18: TORA–7467 TODA–7467 ASDA–6717 LDA–6557
RWY 36: TORA–7195 TODA–7195 ASDA–6907 LDA–6347
SERVICE: S4 FUEL 100LL, JET A1+ OX1, 2, 3 LGT When ATCT clsd, ACTVT MALSR Rwy 36; PAPI Rwy 18 and 36; HIRL Rwy 18–36—CTAF.
AIRPORTREMARKS:Attended 1100–0200Z‡. Svc aft hr—352–682–3911. Rwy sfc conds not rprtd 2200–1200Z‡. 36 calm wind rwy. Rwy 36 RTHL not std. Rwy 18–36 REDL not std. Rwy 18 RENL not std. Twy A1, A8, A9 & A12 E of Twy A; Twy A north of Twy A2; clsd to acr. Twy A1 rstrd to acft with wingspan 60 ft or less. Object 2.5 ft AGL lctd 39 ft north of Twy A1 cntrln. Class IV, ARFF Index A. Index B upon request; CLOSED to acr ops with more than 30 pax seats exc PPR—amgr. Rwy 08–26 not avbl for sked acr opns with more than 9 pax seats or unsked acr at least 31 pax seats. Acft dep Rwy 18 mntn rwy hdg to 800′ AGL or til rchg end of rwy whichever ocrs ltr bfr making left turns. Rwy 18–36 safety area nonstd ireg sfc fm ongoing wildlife burrow mitigation. Rwy 08–26 safety area nonstd ireg sfc fm ongoing wildlife burrow mitigation. Lndg fee: fee for acr ops only. Cstms svc unavbl.
AIRPORT MANAGER: 352-629-8377
WEATHER DATA SOURCES: AWOS–3PT 128.125 (352) 237–8525.
COMMUNICATIONS: CTAF 119.25 ATIS 128.125
RCO 122.1R 113.7T (GAINESVILLE RADIO)
®JACKSONVILLE APP/DEP CON 118.6
TOWER 119.25 (1200–0100Z‡) GND CON 121.4
CLEARANCE DELIVERY PHONE: For CD if una to ctc on FSS freq, ctc Jacksonville Apch at 904-741-0284.
AIRSPACE: CLASS D 1200–0100Z‡; other times CLASS E.
RADIO AIDS TO NAVIGATION: NOTAM FILE OCF.
(VL) (L) VORTAC 113.7 OCF Chan 84 N29°10.65′ W82°13.58′ at fld. 78/0E.
TACAN AZIMUTH unusable:
025°–078°
329°–350°
351°–024° byd 28NM
VOR unusable:
010°–024° byd 40 NM
030°–037° byd 40 NM
053°–060° byd 40 NM
065°–077° byd 40 NM
094°–108° byd 40 NM blo 3,000′
094°–108° byd 66 NM
127°–137° byd 40 NM
157°–171° byd 40 NM blo 13,000′
157°–171° byd 75 NM
177°–187° byd 40 NM blo 2,000′
177°–187° byd 54 NM
193°–210° byd 40 NM
219°–244° byd 40 NM
277°–298° byd 40 NM
325°–335° byd 40 NM blo 10,000′
325°–335° byd 76 NM
352°–005° byd 111 NM
352°–005° byd 40 NM blo 12,000′
ILS 111.5 I–OCF Rwy 36. Class I/A. Localizer unmonitored.
