MOUNT VERNON (MVN)(KMVN) 3 E UTC–6(–5DT) N38°19.40′ W88°51.51′
480 B Class IV, ARFF Index A NOTAM FILE MVN
RWY 05–23: H6496X150 (ASPH–GRVD) S–80, D–108, 2S–95, 2D–190 PCN 33 F/C/X/U HIRL
RWY 05: VASI(V4L)—GA 3.0° TCH 32′. Thld dsplcd 774′. Road.
RWY 23: MALSR. Trees.
RWY 15–33: H3146X100 (ASPH–PFC) S–12 PCN 3 F/B/Y/U MIRL 0.7% up NW
RWY 15: Tree.
RWY 33: Railroad.
RUNWAY DECLARED DISTANCE INFORMATION
RWY 05: TORA–6496 TODA–6496 ASDA–6496 LDA–5722
RWY 15: TORA–3146 TODA–3146 ASDA–3146 LDA–3146
RWY 23: TORA–5572 TODA–5572 ASDA–5572 LDA–5572
RWY 33: TORA–3146 TODA–3146 ASDA–3146 LDA–3146
SERVICE: S4 FUEL 100LL, JET A OX2 LGT ACTIVATE MALSR Rwy 23 —CTAF. ACTIVATE MIRL Rwy 15–33 and HIRL Rwy 05–23 —CTAF night only. Rwy 23 MALSR not avbl dalgt hrs.
AIRPORT REMARKS: Attended 1230–0200Z‡. Migratory waterfowl invof arpt. For svcs after hrs call 618–315–5462. Rwy 15–33 not avbl for unscheduled acr at least 31 psgr seats. Closed to scheduled air carrier ops with greater than 9 passenger seats; Unscheduled air carrier ops greater than 30 passenger seats. 90–day PPR, call 618–242–7016. Rwy 05 also 18′ railroad 238′ from rwy end 498′ right of centerline 2:1 slope. Heliport for private use by medical helicopters only.
AIRPORT MANAGER: 618-242-7016
WEATHER DATA SOURCES: AWOS–3PT 118.2 (618) 242–7933.
COMMUNICATIONS: CTAF/UNICOM 123.0
®KANSAS CITY CENTER APP/DEP CON 127.7
CLEARANCE DELIVERY PHONE: For CD ctc Kansas City ARTCC at 913-254-8508.
AIRSPACE: CLASS E.
RADIO AIDS TO NAVIGATION: NOTAM FILE MVN.
(L) DME 113.8 VNN Chan 85 N38°21.72′ W88°48.44′ 226° 3.3 NM to fld. 558.
ILS 111.7 I–MVN Rwy 23. Class IE.
• • • • • • • • • • • • • • • • • •
HELIPAD H1: H80X40 (CONC) PERIMETER LGTS
