LOUIS ARMSTRONG NEW ORLEANS INTL (MSY)(KMSY) 10 W UTC–6(–5DT) N29°59.60′
W90°15.54′ 3 B LRA Class I, ARFF Index D NOTAM FILE MSY MON Airport
RWY 11–29: H10104X150 (CONC–GRVD) S–75, D–180, 2S–175, 2D–380 PCN 123R/C/W/T HIRL CL
RWY 11: ALSF2. TDZL. PAPI(P4R)–GA 2.8° TCH 73′. RVR–TMR
RWY 29: MALSR. PAPI(P4R)–GA 3.0° TCH 68′. RVR–TMR Thld dsplcd 304′. Tree.
RWY 02–20: H7002X150 (CONC–GRVD) S–75, D–180, 2D–380 PCN 64 R/C/W/T HIRL CL
RWY 02: RLLS. PAPI(P4L)–GA 3.0° TCH 52′. RVR–TR Road.
RWY 20: MALS. PAPI(P4L)–GA 3.0° TCH 52′. RVR–TR Road.
RUNWAY DECLARED DISTANCE INFORMATION
RWY 02: TORA–7002 TODA–7002 ASDA–7002 LDA–7002
RWY 11: TORA–10104 TODA–10104 ASDA–9800 LDA–9800
RWY 20: TORA–7002 TODA–7002 ASDA–6948 LDA–6948
RWY 29: TORA–10104 TODA–10104 ASDA–10104 LDA–9800
SERVICE: FUEL 100LL, JET A
NOISE: Rwy 11 noise sensitive for dep; avbl for opr necessity. All rwys noise sensitive for arr. Arriving turbojets must make 5 mile final apch to minimize noise.
AIRPORT REMARKS: Attended continuously. Flocks of birds on and invof arpt. ASSC in use. Operate transponders with altitude reporting mode and ADS–B (if equipped) enabled on all airport surfaces. 180° and locked wheel turns prohibited on asph sfc acft 12,500 lbs and over. Twy G btn Rwy 11–29 and Twy S sfc mov guidance and ctl system U/S perm. Ldg fee. Flight Notification Service (ADCUS) available.
AIRPORT MANAGER: (504) 303-7652
WEATHER DATA SOURCES: ASOS (504) 471–4486 TDWR.
COMMUNICATIONS: D–ATIS 127.55 (504) 471–4417 UNICOM 122.95
®NEW ORLEANS APP/DEP CON 133.15 (East) 125.5 (West)
TOWER 119.5 GND CON 121.9 CLNC DEL 120.925 PRE TAXI CLNC 120.925
CPDLC (LOGON KUSA)
PDC
AIRSPACE: CLASS B See VFR Terminal Area Chart.
RADIO AIDS TO NAVIGATION: NOTAM FILE MSY.
RESERVE (L) (L) VORW/DME 110.8 RQR Chan 45 N30°05.25′ W90°35.32′ 106° 18.1 NM to fld. 5/2E.
ILS/DME 111.7 I–JFI Chan 54 Rwy 02. Class IE. DME also serves Rwy 20. Autopilot cpd approaches NA blw 880′ MSL.
ILS/DME 109.9 I–MSY Chan 36 Rwy 11. Class IIIE. Lczr Rwy 11/29 interlocked. I–MSY front course, I–HOX back course. DME also serves Rwy 29.
LOC/DME 111.7 I–ONW Chan 54 Rwy 20. DME also serves Rwy 02. DME unusable byd 25° right of course. LOC unusable byd 24° right of course.
ILS/DME 109.9 I–HOX Chan 36 Rwy 29. Class IE. DME also serves Rwy 11. • • • • • • • • • • • • • • • • • •
HELIPAD H1: H50X50 (ASPH)
HELIPAD H2: H50X50 (CONC)
