MODESTO CITY–COUNTY–HARRY SHAM FLD (MOD)(KMOD) 2 SE UTC–8(–7DT) N37°37.55′
W120°57.27′ 99 B NOTAM FILE MOD
RWY 10L–28R: H5904X150 (ASPH–GRVD) S–60, D–200, 2S–175, 2D–400 PCN 38 F/C/X/T HIRL 0.3% up W
RWY 10L: REIL. VASI(V4L)–GA 3.0° TCH 50′. Tree.
RWY 28R: MALSR. Road. Rgt tfc.
RWY 10R–28L: H3464X100 (ASPH) S–30 PCN 8 F/C/X/T MIRL 0.4% up W
RWY 10R: PAPI(P2L)–GA 3.5° TCH 40′. Tree. Rgt tfc.
RWY 28L: PAPI(P2L)–GA 3.0° TCH 29′. Tree.
RUNWAY DECLARED DISTANCE INFORMATION
RWY 10L:TORA–5904 TODA–5904 ASDA–5904 LDA–5904
RWY 10R:TORA–3464 TODA–3464 ASDA–3464 LDA–3464
RWY 28L:TORA–3464 TODA–3464 ASDA–3464 LDA–3464
RWY 28R:TORA–5904 TODA–5904 ASDA–5904 LDA–5904
SERVICE: S4 FUEL 100LL, JET A, A1+ OX 1, 2 LGT When twr clsd, ACTIVATE MALSR Rwy 28R, REIL Rwy 10L, HIRL Rwy 10L–28R–CTAF. PAPI Rwy 10R and Rwy 28L and MIRL Rwy 10R–28L unavailable when twr clsd.
NOISE: For NS ABTMT turbojets discontinue ops 0800–1300Z‡ and park on NE ramp. NS ABTMT procedures, pilots are reqd to use lgtd rwy only.
AIRPORT REMARKS: Attended Mon–Fri 1600–0030Z‡. Rwy 10R–28L CLOSED to acft over 12,500 lbs GWT. Birds and small mammals on and invof arpt. Ponding along north edge of Twy B dur and after wet wx. PPR 72 hrs for air carrier ops with more than 30 pax seats 1600–0100Z‡ wkdays call arpt mgr 209–577–5318. All pure jet and large acft ltd to parking and svc at NE ramp only. Rwy 10R–28L not certificated in accordance with FAR–139. Overngt tiedown fee.
AIRPORT MANAGER: 209-577-5318
WEATHER DATA SOURCES: ASOS 127.7 (209) 572–0914. ASOS oper 0500–1500Z‡. LAWRS (1500–0500Z‡).
COMMUNICATIONS: CTAF 125.3 ATIS 127.7 UNICOM 122.95
RCO 122.1R 114.6T (RANCHO MURIETA RADIO)
TOWER 125.3 (1500–0500Z‡) GND CON 121.7
CLEARANCE DELIVERY PHONE: For CD when ATCT clsd ctc NorCal Apch at 916-361-0516.
AIRSPACE: CLASS D svc 1500–0500Z‡; other times CLASS G.
RADIO AIDS TO NAVIGATION: NOTAM FILE MOD.
(VH) (DH) VOR/DME 114.6 MOD Chan 93 N37°37.64′ W120°57.47′ at fld. 93/17E. Aerobatic acft wi an area defined as .5 NM rds of MOD 032028 (7.5 NM SW O22), blo 4800′, avoidance advised dly SR–SS
VOR unusable:
005°–009° byd 40 NM
028°–083° byd 40 NM
092°–097° byd 40 NM
112°–121° byd 40 NM
130°–145° byd 40 NM blo 4,000′
130°–145° byd 62 NM
146°–156° byd 40 NM
170°–185° byd 40 NM
186°–196° byd 40 NM blo 5,000′
186°–196° byd 49 NM
197°–338° byd 40 NM
ILS 111.9 I–MOD Rwy 28R. Class IA. Unmonitored when ATCT closed. Autocoupled approaches NA blo 1,080′ MSL (2.8 NM fm thld).
COMM/NAV/WEATHER REMARKS: Aviation wx avbl when twr opr, call 209–526–4555.
