LIVERMORE MUNI (LVK)(KLVK) 3 W UTC–8(–7DT) N37°41.60′ W121°49.22′
400 B NOTAM FILE LVK
RWY 07L–25R: H5253X100 (ASPH–GRVD) S–45, D–90 HIRL 0.5% up E
RWY 07L: PAPI(P4R)–GA 4.0° TCH 32′. Tree.
RWY 25R: MALSR. VASI(V4L)–GA 3.0° TCH 48′. Bldg. Rgt tfc.
RWY 07R–25L: H2699X75 (ASPH) S–12.5 MIRL 0.6% up E
RWY 07R: Rgt tfc.
SERVICE: S4 FUEL 100LL, JET A OX 1, 3 LGT When twr clsd ACTIVATE MALSR Rwy 25R; twy lgts–118.1. HIRL Rwy 07L–25R opr low ints; to increase ints ACTIVATE 118.1. MIRL Rwy 07R–25L opr low ints; not avbl when twr clsd. PAPI Rwy 07L and VASI Rwy 25R opr continuously. Rwy 07L–25R edge lgt on low and medium int level on downwind leg of tfc pattern difficult to see.
NOISE: Noise sensitive areas 3/4 mile east and 2 miles west of arpt. Pls obs "voluntary restraint from night flying 0600–1400Z‡ policy."
AIRPORT REMARKS: Attended Mon–Fri 1530–0100Z‡, Sat–Sun 1500–1900Z‡. Be alert to considerable bird activity on and invof arpt. Do not mistake parallel twy N of Rwy 25R–07L as rwy. NOTE: See Special Notices–Arrival Alert.
AIRPORT MANAGER: 925-960-8230
WEATHER DATA SOURCES: ASOS (925) 606–5412 LAWRS.
COMMUNICATIONS: CTAF 118.1 ATIS 119.65 925–447–9516 UNICOM 122.95
®NORCAL APP CON 123.85 (07R–25L, 07L–25R)
®NORCAL DEP CON 123.85 (07R, 07L) 125.35 (25R, 25L)
TOWER 118.1 (1500–0500Z‡) GND CON 121.6
CLEARANCE DELIVERY PHONE: For CD when ATCT is clsd ctc NorCal Apch at 916-361-0516.
AIRSPACE: CLASS D svc 1500–0500Z‡; other times CLASS G.
RADIO AIDS TO NAVIGATION: NOTAM FILE OAK.
OAKLAND (VH) (DH) VORW/DME 116.8 OAK Chan 115 N37°43.56′ W122°13.42′ 079° 19.3 NM to fld. 13/17E.
DME unusable:
340°–040° byd 30 NM blo 8,000′
VOR unusable:
116°–126° byd 105 NM
116°–126° byd 40 NM blo 5,000′
116°–126° byd 52 NM blo 12,000′
130°–140° byd 40 NM blo 14,000′
130°–140° byd 55 NM
146°–156° byd 40 NM blo 7,000′
146°–156° byd 49 NM blo 11,000′
146°–156° byd 83 NM
157°–183° byd 40 NM
198°–213° byd 40 NM
214°–224° byd 40 NM blo 14,000′
214°–224° byd 65 NM
230°–240° byd 40 NM blo 14,500′
230°–240° byd 85 NM
241°–250° byd 40 NM
251°–263° byd 40 NM blo 31,000′
275°–298° byd 40 NM
314°–320° byd 40 NM
338°–352° byd 40 NM blo 18,000′
338°–352° byd 40 NM blo 8,500′
353°–115° byd 40 NM
ILS/DME 110.5 I–LVK Chan 42 Rwy 25R. Class IE.
COMM/NAV/WEATHER REMARKS: Emerg frequency 121.5 not avbl at tower. • • • • • • • • • • • • • • • • • •
HELIPAD H1: H24X22 (ASPH)
