WILMINGTON INTL (ILM)(KILM) P (AF) 3 NE UTC–5(–4DT) N34°16.27′ W77°54.17′
32 B LRA Class I, ARFF Index B NOTAM FILE ILM
RWY 06–24: H8016X150 (ASPH–GRVD) S–75, D–160, 2S–175, 2D–275 PCN 78 F/B/W/T HIRL
RWY 06: REIL. PAPI(P4R)—GA 3.0° TCH 57′. RVR–TR
RWY 24: MALSR. PAPI(P4L)—GA 3.0° TCH 48′. RVR–TR
RWY 17–35: H7754X150 (ASPH–GRVD) S–60, D–185, 2S–175, 2D–300 PCN 61 F/B/W/T HIRL
RWY 17: REIL. PAPI(P4L)—GA 3.0° TCH 50′. RVR–R Thld dsplcd 350′.
RWY 35: MALSR. PAPI(P4L)—GA 3.0° TCH 36′. RVR–T Thld dsplcd 400′.
RUNWAY DECLARED DISTANCE INFORMATION
RWY 06: TORA–8016 TODA–8016 ASDA–8016 LDA–8016
RWY 17: TORA–7754 TODA–7754 ASDA–6954 LDA–6604
RWY 24: TORA–8016 TODA–8016 ASDA–8016 LDA–8016
RWY 35: TORA–7754 TODA–7754 ASDA–7604 LDA–7204
SERVICE: S4 FUEL 100LL, JET A, A+ OX 1, 2, 3, 4 LGT Actvt MALSR Rwy 24 and 35; REIL Rwy 06 and 17; PAPI Rwy 06, 17, 24; HIRL Rwy 06–24 and17–35; and all twy lgts—CTAF. MILITARY— FUEL A, A+ (C910–763–4691.) (NC–100LL)
AIRPORT REMARKS: Attended continuously. Acft taxiing from south ramp obtain ATC clnc prior to crossing Rwy 17–35 1100–0400Z‡. Traffic pattern alt 1000′ AGL reciprocating engine, 1500′ AGL tbjt/jet. OHD: 5 mile initial 2500 ft AGL, break 2000 ft AGL. Tower calls drctn of break. Carrier break NA. Flight Notification Service (ADCUS) avbl.
AIRPORT MANAGER: 910-341-4333
WEATHER DATA SOURCES: ASOS (910) 254–5254
COMMUNICATIONS: CTAF 119.9 ATIS 124.975 UNICOM 122.95
RCO 122.6 (RALEIGH RADIO)
RCO 122.1R 117.0T (RALEIGH RADIO)
®APP/DEP CON 135.75 317.425 (344°–163°) 118.25 284.65 (164°–343°) (1100–0400Z‡)
®WASHINGTON CENTER APP/DEP CON 135.75 317.425 (0400–1100Z‡)
TOWER 119.9 239.3 (1100–0400Z‡) GND CON 121.9 348.6
CLEARANCE DELIVERY PHONE: For CD if una to ctc on FSS freq, ctc Washington ARTCC at 703-771-3587.
AIRSPACE: CLASS D svc 1100–0400Z‡; other times CLASS E.
TRSA svc ctc APP CON within 20 NM
RADIO AIDS TO NAVIGATION: NOTAM FILE ILM.
(H) (H) VORTAC 117.0 ILM Chan 117 N34°21.10′ W77°52.46′ 203° 5.0 NM to fld. 29/7W.
VOR portion unusable:
051°–185°
164°–051° blo 17,500′
186°–229° blo 3,000′
230°–315° byd 5 NM blo 17,500′
316°–050° blo 8,000′
TACAN DME unusable:
015°–305° byd 30 NM blo 2,500′
TACAN AZIMUTH unusable:
129°–160° byd 30 NM blo 2,500′
WILZE NDB (LOMW) 205 GM N34°20.24′ W77°48.71′ 239° 6.0 NM to fld. 28/10W.
AIRLI NDB (LOMW) 281 IL N34°11.48′ W77°51.98′ 349° 5.1 NM to fld. 12/10W.
ILS/DME 109.95 I–GNM Chan 36(Y) Rwy 06. Class IE.
ILS 111.55 I–GMX Rwy 24. Class IIE. LOM WILZE NDB.
ILS 110.3 I–ILM Rwy 35. Class IT. LOM AIRLI NDB.
