KENOSHA RGNL (ENW)(KENW) 4 W UTC–6(–5DT) N42°35.76′ W87°55.64′
743 B NOTAM FILE ENW
RWY 07L–25R: H6600X100 (CONC–GRVD) S–62, D–73, 2S–85, 2D–135 HIRL 0.5% up W
RWY 07L: MALSR. PAPI(P4L)—GA 3.0° TCH 55′.
RWY 25R: REIL. PAPI(P4L)—GA 3.0° TCH 45′. Rgt tfc.
RWY 15–33: H4440X100 (CONC–GRVD) S–62, D–73, 2S–86, 2D–135 HIRL
RWY 15: VASI(V4L)—GA 4.0° TCH 50′. Trees.
RWY 33: VASI(V4L)—GA 3.0° TCH 42′.
RWY 07R–25L: H3302X75 (ASPH–CONC) S–40, D–48 MIRL 0.7% up W
RWY 07R: PAPI(P4L)—GA 3.0° TCH 26′. Rgt tfc.
RWY 25L: PAPI(P4L)—GA 3.0° TCH 24′.
SERVICE: S4 FUEL 100LL, JET A OX 1, 2 LGT When twr clsd HIRL Rwy 07L–25R preset on low intst; to incr intst and ACTIVATE MALSR Rwy 07L; REIL Rwy 25R; PAPI Rwy 07L, Rwy 07R, Rwy 25L and Rwy 25R; HIRL Rwy 07L–25R; HIRL Rwy 15–33; MIRL Rwy 07R–25L—CTAF. VASI Rwy 15 and Rwy 33 opr consly. Rwy end 25L: PAPI unusbl byd 7 degs right of cntrln.
AIRPORT REMARKS: Attended 1300–0300Z‡. Birds on and invof arpt. Rwy 07R–25L is CLOSED to jet acft and acft weighing more than 12,500 lbs when Rwy 07L–25R is open. Acft weighing more than 122,000 lbs, empty or fully loaded, are not allowed to be based at KENW. The term "based" shall be defined as an acft that is opr and airworthy on the arpt for a majority of the year. Helicopter dep and arr ops will be authorized by twr from movement areas only. Non–movement area deps, arrs and practice, are prohibited.
AIRPORT MANAGER: 262-653-4161
WEATHER DATA SOURCES: ASOS (262) 652–7730
COMMUNICATIONS: CTAF 118.6 ATIS 127.175 UNICOM 122.95
®MILWAUKEE APP/DEP CON 135.875
TOWER 118.6 (1300–0300Z‡) GND CON 121.875
CLNC DEL 121.875 (118.6 when twr clsd)
AIRSPACE: CLASS D svc 1300–0300Z‡; other times CLASS E.
RADIO AIDS TO NAVIGATION: NOTAM FILE IKK.
NORTHBROOK (VH)(DH)VORW/DME 113.0 OBK Chan 77 N42°13.28′ W87°57.10′ 005° 22.5 NM to fld. 708/2W.
DME unusable:
215°–330° byd 35 NM blo 3,000′
VOR unusable:
265°–272° byd 40 NM
273°–283° byd 40 NM blo 18,000′
284°–288° byd 40 NM
(T) DME 109.2 ENW Chan 29 N42°35.94′ W87°55.90′ at fld. 734. NOTAM FILE ENW.
ILS 109.35 I–ENW Rwy 07L. Class IB. Unmonitored when ATCT clsd.
