CHESTER CATAWBA RGNL (DCM)(KDCM) 5 N UTC–5(–4DT) N34°47.36′ W81°11.75′
657 B NOTAM FILE AND
RWY 17–35: H5000X100 (ASPH) S–30, D–44 MIRL 0.4% up N
RWY 17: PAPI(P2L)—GA 3.0° TCH 26′. Tree. Rgt tfc.
RWY 35: PAPI(P2L)—GA 3.0° TCH 32′. Tree.
RWY 05–23: H4998X100 (ASPH) S–4, D–12 0.4% up SW
RWY 05: Thld dsplcd 949′. Tree. Rgt tfc.
RWY 23: Tree.
SERVICE: FUEL 100LL, JET A LGT ACTIVATE PAPI Rwy 17 and Rwy 35; MIRL Rwy 17–35—CTAF.
AIRPORT REMARKS: Attended Mon–Sat 1400–2300Z‡, Sun 1800–2300Z‡. Parachute Jumping. For fuel or any svc aft hrs call 803–385–6664. Rwy 05–23 PCI Rating 40 very poor.
AIRPORT MANAGER: 803-385-6664
WEATHER DATA SOURCES: AWOS–3 120.975 (803) 385–2011.
COMMUNICATIONS: CTAF/UNICOM 122.7
®CHARLOTTE APP/DEP CON 120.05
CLEARANCE DELIVERY PHONE: For CD ctc Charlotte Apch at 704-359-0241.
RADIO AIDS TO NAVIGATION: NOTAM FILE CLT.
CHARLOTTE (L) (L) VORW/DME 115.0 CLT Chan 97 N35°11.42′ W80°57.11′ 212° 26.9 NM to fld. 732/5W.
DME portion unusable:
015°–050° byd 25 NM blo 3,000′
050°–100° byd 25 NM blo 2,500′
185°–202° byd 15 NM
203°–220°
270°–350° byd 20 NM blo 5,000′
VOR/DME controlled by Charlotte ATCT
VOR unusable:
203°–220°
(DL) DME 116.35 XKD Chan 110(Y) N34°46.98′ W81°11.90′ at fld. 635. NOTAM FILE AND.
NDB (MHW) 220 DCM N34°47.15′ W81°12.05′ at fld. 657/6W. NOTAM FILE AND.
