NAPA CO (APC)(KAPC) 5 S UTC–8(–7DT) N38°12.79′ W122°16.84′
36 B NOTAM FILE APC MON Airport
RWY 01L–19R: H5930X150 (ASPH–GRVD) S–102, D–134, 2D–120 PCN 41 F/D/X/T MIRL 0.3% up N
RWY 01L: MALS.
RWY 19R: PAPI(P4L)–GA 3.25° TCH 52′. Rgt tfc.
RWY 06–24: H5008X150 (CONC) S–60, D–76, 2D–120 PCN 21 R/C/W/T MIRL 0.4% up NE
RWY 06: REIL.
RWY 01R–19L:H2510X75 (ASPH) S–13.5 PCN 5 F/D/X/T 0.4% up N
RWY 01R: Rgt tfc.
LAND AND HOLD–SHORT OPERATIONS
LDG RWY HOLD–SHORT POINT AVBL LDG DIST
RWY 24 01L–19R 3700
SERVICE: S4 FUEL 100LL, JET A OX 3, 4 LGT When twr clsd ACTIVATE MALS Rwy 01L; REIL Rwy 06, MIRL Rwy 01L–19R and Rwy 06–24–CTAF. PAPI Rwy 19R opr continuously.
AIRPORT REMARKS: Attended 1500–0400Z‡. For fuel svc 0500–1400Z‡ call 707–224–0887. Unlgt bridge 1 NM S, 167′ AGL. Asph apron strength 12,500–30,000 lbs gross weight single wheel. Due to arpt proximity to wetlands birds on and invof the arpt year around with highest concentration of activity of birds on the rwys during rainy weather. Landing fee. Ldg fee chrgd to all air taxi, coml acft ops (exc flt instruction), and trans acft weighing more than 12500 lbs.
AIRPORT MANAGER: 707-253-4300
WEATHER DATA SOURCES: ASOS (707) 252–7916
COMMUNICATIONS: CTAF 118.7 ATIS 124.05 707–255–2847 UNICOM 122.95
®OAKLAND CENTER APP/DEP CON 127.8 353.5
TOWER 118.7 (1500–0400Z‡) GND CON 121.7 CLNC DEL 127.85
CLEARANCE DELIVERY PHONE: For CD when ATCT clsd ctc Oakland ARTCC at 510-745-3380.
AIRSPACE: CLASS D svc 1500–0400Z‡; other times CLASS G.
RADIO AIDS TO NAVIGATION: NOTAM FILE APC.
SCAGGS ISLAND (VL) (H) VORTACW 112.1 SGD Chan 58 N38°10.76′ W122°22.39′ 048° 4.8 NM to fld. 5/17E.
VOR unusable:
064°–068° byd 40 NM
082°–087° byd 40 NM
098°–112° byd 40 NM blo 8,000′
098°–112° byd 74 NM
190°–239° byd 40 NM
244°–257° byd 40 NM
285°–303° byd 40 NM
310°–331° byd 40 NM
336°–045° byd 40 NM
ILS/DME 111.3 I–APC Chan 50 Rwy 01L. Class IE. LOC unmonitored when ATCT clsd. Glideslope unusable byd 4° left and 7° right of course. Autopilot coupled apchs not applicable blw 530′ MSL (1.3 NM from thld).
