ALBUQUERQUE
ALBUQUERQUE INTL SUNPORT (ABQ)(KABQ) P (AF ANG DOE USFS) 3 SE UTC–7(–6DT) N35°02.34′ W106°36.50′ 5355 B LRA ARFF Index–See Remarks NOTAM FILE ABQ MON Airport
RWY 08–26: H13793X150 (CONC–GRVD) S–100, D–210, 2S–175, 2D–360, 2D/2D2–720 PCN 71 R/B/W/T HIRL CL
RWY 08: MALSR. TDZL. VASI(V6L)–GA 2.95° TCH 55′. RVR–T Thld dsplcd 1000′. Rgt tfc.
RWY 26: REIL. PAPI(P4L)–GA 3.0° TCH 83′. RVR–R 0.5% down.
RWY 03–21: H10000X150 (CONC–GRVD) S–100, D–210, 2S–175, 2D–360, 2D/2D2–720 PCN 78 R/B/W/T HIRL CL
RWY 03: MALSR. TDZL. PAPI(P4L)–GA 3.0° TCH 59′. RVR–TR Rgt tfc.
RWY 21: REIL. PAPI(P4L)–GA 3.0° TCH 74′. RVR–TR
RWY 12–30: H6000X150 (CONC–GRVD) S–65, D–120, 2S–155, 2D–155 PCN 41 R/C/W/T MIRL
RWY 12: RVR–R Rgt tfc.
RWY 30: REIL. PAPI(P4L)–GA 3.0° TCH 46′. RVR–T
RUNWAY DECLARED DISTANCE INFORMATION
RWY 03: TORA–10000 TODA–10000 ASDA–10000 LDA–10000
RWY 08: TORA–13793 TODA–13793 ASDA–13793 LDA–12793
RWY 12: TORA–6000 TODA–6000 ASDA–6000 LDA–6000
RWY 21: TORA–10000 TODA–10000 ASDA–10000 LDA–10000
RWY 26: TORA–13793 TODA–13793 ASDA–13793 LDA–13793
RWY 30: TORA–6000 TODA–6000 ASDA–6000 LDA–6000
SERVICE: S4 FUEL 100LL, JET A, A1, A1+ OX 1, 2, 3, 4 LGT PAPI Rwy 26 does not prvd obst clnc byd 3.5 NM fm thr; unusbl byd 3.5 NM.
AIRPORT REMARKS: Attended continuously. Bird haz Oct–Dec and Mar–May; student hel tfc. Ctl firing area S. Rwy 03–21 130 ft wid. Rwy 08–26 130 ft wid. Rwy 12–30 130 ft wid. Rwy 03 dep rstrd; PPR–ATCT. Rwy 08 and 12 apch end decoupled; common hold short line shared. Rwy 12 tkof via Txy E; full len avbl via back tax. Rwy 08 & 12 apch ends decoupled; commong hold short line shared. Rwy 30 lndg: last avbl exit Txy E; exit E1 not posbl. Twy E5 clsd. Class I, ARFF Index C. ARFF prvdd by USAF. Fighter acft dep S only. Acr gnd handling NA 0800–1130Z‡. Twy H mil use only. Mil wx svc avbl 1100–0600Z‡ Mon; 1300–0600Z‡ Tues–Fri. Clsd wkend hol and down days. Aft hr msn wx support briefings – 25 OWS/Davis–Monthan AFB D228–6604/C520–228–6604. NWS KABQ FCST–D246–9707/C505–846–9707. FAA obs H24 C505–246–4200. Flight Notification Service (ADCUS) available.
AIRPORT MANAGER: 505-244-7700
WEATHER DATA SOURCES: ASOS (505) 242–4044 LLWAS. WSP.
COMMUNICATIONS: D–ATIS 118.0 505–856–4928 UNICOM 122.95
RCO 122.3 (ALBUQUERQUE RADIO)
WEST MESA RCO 122.5 (ALBUQUERQUE RADIO)
®APP CON 123.9 (S of V12) 127.4 (on or N of V12) 126.3
®DEP CON 127.4 (on or N of V12) 123.9 (S of V12)
TOWER 120.3 123.775 GND CON 121.9 CLNC DEL 119.2
CPDLC (LOGON KUSA)
PDC
AIRSPACE: CLASS C svc ctc APP CON.
VOR TEST FACILITY (VOT) 111.0
RADIO AIDS TO NAVIGATION: NOTAM FILE ABQ.
(VH) (H) VORTACW 113.2 ABQ Chan 79 N35°02.63′ W106°48.98′ 079° 10.3 NM to fld. 5749/13E.
TACAN AZIMUTH unusable:
040°–055° byd 30 NM blo 15,000′
VOR unusable:
039°–078° byd 40 NM
111°–133° byd 40 NM blo 14,000′
211°–216° byd 40 NM blo 9,000′
211°–216° byd 52 NM
257°–262° byd 40 NM blo 9,000′
257°–262° NM byd 63 NM
271°–280° byd 40 NM blo 13,300′
271°–280° byd 49 NM
281°–327° byd 40 NM blo 11,000′
281°–327° byd 63 NM
327°–333° byd 40 NM blo 11,500′
ILS 111.5 I–BZY Rwy 03. Class IE.
ILS/DME 111.9 I–SPT Chan 56 Rwy 08. Class IE.
ASR
COMM/NAV/WEATHER REMARKS: PMSV OTS; ltd blw 10000 ft 010–070. PTD OTS.
