MWLMINERAL WELLS RGNL
MINERAL WELLS, TX   [chart] [wx] [tpp]
MINERAL WELLS RGNL (MWL)(KMWL) 3 SE UTC–6(–5DT) N32°46.90′ W98°03.61′
974 B NOTAM FILE MWL MON Airport
RWY 13–31: H5996X100 (ASPH) S–50, D–145, 2S–175 MIRL 0.9% up SE
RWY 13: PAPI(P4L)–GA 3.0° TCH 40′. Thld dsplcd 300′. Fence.
RWY 31: PAPI(P4L)–GA 3.0° TCH 53′. Thld dsplcd 400′. Trees.
RWY 17–35: H4188X100 (ASPH) S–50, D–145, 2S–175 MIRL 1.0% up S
RWY 17: PAPI(P2R)–GA 3.0° TCH 43′. Trees.
RWY 35: PAPI(P2L)–GA 4.0° TCH 46′. Thld dsplcd 286′. Trees.
SERVICE: FUEL 100LL, JET A LGT Dusk–Dawn. MIRL Rwy 13–31 and Rwy 17–35 preset low intst; to incr intst ACTVT–CTAF. Rwy 35 PAPI unusable byd 3° left of centerline.
AIRPORT REMARKS: Attended 1200–0200Z‡. For fuel after hrs call 940–328–7770. Rwy 13–31 rwy ends not visible from opposite end.
AIRPORT MANAGER: 940-328-7809
WEATHER DATA SOURCES: ASOS 135.075 (940) 325–2457.
COMMUNICATIONS: CTAF/UNICOM 122.725
RCO 122.2 (FORT WORTH RADIO)
®FORT WORTH CENTER APP/DEP CON 127.0
CLEARANCEDELIVERY PHONE:For CD if una to ctc on FSS freq, ctc Fort Worth ARTCC at 817-858-7584.
AIRSPACE: CLASS E svc continuous.
RADIO AIDS TO NAVIGATION: NOTAM FILE FTW.
MILLSAP (VH) (H) VORTACW 117.7 MQP Chan 124 N32°43.57′ W97°59.85′ 307° 4.6 NM to fld. 9009E.
VOR unusable:
004°–009° byd 40 NM
010°–054° byd 40 NM blo 3,800′
010°–054° byd 46 NM blo 5,000′
010°–054° byd 56 NM
055°–066° byd 40 NM blo 3,800′
055°–066° byd 50 NM
230°–247° byd 40 NM
248°–258° byd 40 NM blo 3,700′
248°–258° byd 53 NM
259°–270° byd 40 NM blo 6,000′
259°–270° byd 63 NM
271°–285° byd 40 NM
312°–316° byd 40 NM
325°–340° byd 40 NM blo 3,000′
325°–340° byd 46 NM blo 5,000′
325°–340° byd 66 NM
353°–003° byd 40 NM blo 18,000′
ILS/DME 109.55 I–VMH Chan 32(Y) Rwy 31. Class IE. Unmonitored.
