HAWAII
BRADSHAW ARMY AIRFIELD (BSF)(PHSF) 1 W UTC–10 N19°45.60′ W155°33.23′ 6190 TPA–See Remarks NOTAM FILE HNL
RWY 09–27: H3696X90 (ASPH) PCN 27 F/B/W/T MIRL
RWY 09: PAPI(P4L)–GA 3.0° TCH 30′. Rgt tfc. 2.9% up E.
RWY 27: Terrain. Rgt tfc.
SERVICE: FUEL 100LL, JET A LGT ACTIVATE MIRL Rwy 09–27, PAPI Rwy 09–121.7. FUEL JAA/F24–24 hr PPR, fuel only tran acft, MIL EXER acft unit shall provide fuel. J8 (MIL) 24 hr PPR 1730–0000Z Mon–Fri except holidays, C808–969–2461. TRAN ALERT No aerospace gnd eqpt, tran alert or maint svc. Ltd acft parking.
MILITARY REMARKS:Attended Mon–Fri 1715–0100Z except holidays, phone Honolulu C808–433–1810 extn 461. Terminal, planes and marked twr on arpt. Arpt is VFR for mil training. Parachute Jumping. RSTD PPR for full stop ldg, parking and for non–tenant acft. 72 hrs PPR for hazardous cargo ops, fixed wing ops, and code movement, 24 hr PPR for all tran acft; overflight of ammo supply point located 3300′ South of airfield is prohibited. Hazardous cargo on/off load approach end Rwy 09 only. Hazardous cargo advise twr IAW AR 95–27/AFR 55–14/OPNAVINST. Flight within 4900′ or direct overflight blo 9000′ over Mauna Kea State Park located 8200′ ESE of airfield is prohibited. Flt within 3/4 NM or overflight below 7,000′ of Waikii Ranch 7.9 NM NW prohibited. No acft with skids on Fixed Wing ramp. When twr closed, acft remain N of Saddle Road and establish two–way communication with Range Control prior to entry R–3103. Fixed wing acft are not auth tkof Rwy 09 and Rwy 27. Fixed wing tkof and ldg not avbl when twr clsd. Fixed wing apch/land Rwy 09 only. Overflight or landing at Kawaihae Docks is prohibited for military acft. CAUTION Located in R–3103. 500′ asph overrun each end of Rwy 09–27. 7′ lip at W end of overrun. 75′ of lava rock each side of rwy for dust control. Extensive dust hazard to fixed wing acft on E and W copter park ramps. High FOD potential in all areas of airfield. Extensive copter tfc vicinity of arpt. Terrain rises rapidly N of fld to 13,796 MSL. Overrun available for takeoff Rwy 27 end. High winds and low level wind shear may exist. Wildlife haz mult ungalates (sheep/goats) may be on or near rwy. TFC PAT TPA–Tfc pattern R/W N of rwy, 6900′. Fixed wing 7700′ or as directed by ATC. MISC Ltd ARFF facilities for scheduled flights during airfield opr hrs. Base wx station open Mon–Fri 1700–0100Z exc holidays. Wx observers view obstructed by buildings S–SW. Remote wx briefings avbl from 17 OWS wx Squadron 24 hrs at DSN/COMM 449–8333, 2 hr prior notice required for brief.
AIRPORT MANAGER: 808-961-6232
COMMUNICATIONS: CTAF 119.275 ATIS 124.7
KAMUELA RCO 122.1R 113.3T (HONOLULU RADIO)
HCF CENTER APP/DEP CON 118.45 (1715–0100Z Except Holidays) 278.3
TOWER 119.275 (1715–0100Z Mon–Fri) GND CON 121.7
HICKAM METRO 346.6 Remote brief avbl. RANGE 141.05 38.3 (Opr 24 hrs)
PMSV METRO 122.75
CLEARANCE DELIVERY PHONE: For CD when ATCT clsd, ctc Honolulu Control Facility at 808-840-6262.
AIRSPACE: CLASS D svc 1715–0100Z‡ Mon–Fri exc hol; other times CLASS G.
RADIO AIDS TO NAVIGATION: NOTAM FILE MUE.
KAMUELA (H) VOR/DME 113.3 MUE Chan 80 N19°59.88′ W155°40.19′ 144° 15.7 NM to fld. 267011E.
VOR portion unusable:
001°–030° byd 10 NM blo 6,000′
070°–084° byd 25 NM blo 7,000′
070°–084° byd 35 NM blo 13,000′
085°–210° byd 15 NM blo 15,500′
290°–360° byd 10 NM blo 7,500′
290°–360° byd 20 NM blo 16,000′
DME unusable:
070°–084° byd 25 NM blo 7,000′
070°–084° byd 35 NM blo 13,000′
085°–210° byd 15 NM blo 15,500′
290°–030° byd 10 NM
HILO (H) VORTAC 116.9 ITO Chan 116 N19°43.28′ W155°00.66′ 263° 30.8 NM to fld. 23/11E. NOTAM FILE ITO.
COMM/NAV/WEATHER REMARKS:PMSV unreadable blo 6190′ and vicinity mountains. Svc is avbl only when afld is opr. PTA range ATIS 132.5/244.250.
