FARMINGTON
FOUR CORNERS RGNL (FMN)(KFMN) 1 NW UTC–7(–6DT) N36°44.48′ W108°13.80′ 5507 B Class III, ARFF Index A NOTAM FILE FMN
RWY 07–25: H6704X100 (ASPH–PFC) S–50, D–90, 2S–114 PCN 29 F/C/X/T MIRL 0.4% up E
RWY 07: VASI(V4L)–GA 3.0° TCH 50′. Thld dsplcd 239′.
RWY 25: REIL. VASI(V4L)–GA 3.0° TCH 55′. Thld dsplcd 217′.
RWY 05–23: H6501X150 (ASPH–GRVD) S–47, D–66, 2S–84 PCN 29 F/C/X/T MIRL 0.5% up NE
RWY 05: PAPI(P4L)–GA 3.0° TCH 42′.
RWY 23: REIL. PAPI(P4R)–GA 3.0° TCH 42′. Thld dsplcd 511′.
RUNWAY DECLARED DISTANCE INFORMATION
RWY 05: TORA–6501 TODA–6501 ASDA–5590 LDA–5590
RWY 07: TORA–6704 TODA–6704 ASDA–6487 LDA–6248
RWY 23: TORA–6501 TODA–6501 ASDA–6101 LDA–5590
RWY 25: TORA–6704 TODA–6704 ASDA–6465 LDA–6248
SERVICE: S4 FUEL 100LL, JET A, A1+ OX2, 4 LGT When ATCT clsd ACTVT REIL Rwy 23 and 25; PAPI Rwy 05 and 23; VASI Rwy 07 and 25; MIRL Rwy 05–23 and 07–25–CTAF. REIL Rwy 25 and MIRL Rwy 07–25 preset low intst.
AIRPORT REMARKS: Attended 1300–0500Z‡. Arpt surface conditions are not monitored outside of attended hours.
AIRPORT MANAGER: 505-599-1394
WEATHER DATA SOURCES: ASOS 127.15 (505) 325–9268. LAWRS SAWRS.
COMMUNICATIONS: CTAF 118.9 ATIS 127.15 UNICOM 122.95
FARMINGTON RCO 122.4 (ALBUQUERQUE RADIO)
®DENVER CENTER APP/DEP CON 118.575
FARMINGTON TOWER 118.9 (1300–0500Z‡) GND CON 121.7
CLEARANCE DELIVERY PHONE: For CD ctc farmington ATCT ground control 121.7, when ATCT clsd ctc Denver ARTCC at 303-651-4257
AIRSPACE: CLASS D svc 1300–0500Z‡; other times CLASS E.
RADIO AIDS TO NAVIGATION: NOTAM FILE FMN.
RATTLESNAKE (VH) (H) VORTACW 115.3 RSK Chan 100 N36°44.90′ W108°05.93′ 252° 6.3 NM to fld. 5821/14E.
VOR unusable:
007°–017° byd 40 NM blo 18,000′
018°–041° byd 40 NM
042°–062° byd 40 NM blo 15,000′
042°–062° byd 63 NM blo 20,000′
063°–066° byd 40 NM
067°–077° byd 40 NM blo 14,000′
067°–077° byd 75 NM
078°–094° byd 40 NM
095°–105° byd 40 NM blo 18,000′
106°–119° byd 40 NM blo 11,500′
106°–119° byd 62 NM blo 12,500′
106°–119° byd 76 NM
120°–125° byd 40 NM
235°–255° byd 40 NM blo 12,000′
235°–255° byd 84 NM blo 28,000′
256°–274° byd 40 NM
275°–285° byd 40 NM blo 30,000′
286°–327° byd 40 NM
328°–338° byd 40 NM blo 15,000′
344°–356° byd 40 NM blo 16,300′
344°–356° byd 66 NM
357°–006° byd 40 NM
ILS/DME 111.9 I–FMN Chan 56 Rwy 25. Class IE. Unmonitored when ATCT clsd.
