CHARLESTON
WEST VIRGINIA INTL YEAGER (CRW)(KCRW) P (ANG) 3 E UTC–5(–4DT) N38°22.56′ W81°35.57′ 947 B LRA Class I, ARFF Index B NOTAM FILE CRW MON Airport
RWY 05–23: H6715X150 (ASPH–GRVD) S–120, D–250, 2S–175, 2D–389, 2D/2D2–917 PCR 950 F/D/X/T HIRL CL 0.8% up SW
RWY 05: REIL. PAPI(P4L)–GA 3.0° TCH 56′. RVR–TR Pole.
RWY 23: ALSF1. VASI(V4R)–GA 3.0° TCH 56′. RVR–TR Thld dsplcd 500′. Pole.
RUNWAY DECLARED DISTANCE INFORMATION
RWY 05: TORA–6715 TODA–6715 ASDA–6215 LDA–6215
RWY 23: TORA–6715 TODA–6715 ASDA–6715 LDA–6215
ARRESTING GEAR/SYSTEM
RWY 23: EMAS
SERVICE: S4 FUEL 100LL, JET A MILITARY– A–GEAR Rwy 23 EMAS 328′ x 170′. JASU 6(MD–3) 1(MA–1A) FUEL A++ (Mil), A+ (C304–343–8818) (NC–100LL) FLUID LOX OIL O–156(Mil)
AIRPORT REMARKS: Attended continuously. Fuel svc ctc 304–346–9977. Birds and deer on and invof arpt. Rwy 23 mil assault ldg zone and precision intrument markings. Ldg fee not applicable to based acft. Flight Notification Service (ADCUS) available.
AIRPORT MANAGER: 304-344-8033
WEATHER DATA SOURCES: ASOS (304) 346–4797 LLWAS.
COMMUNICATIONS: ATIS 127.6 UNICOM 122.95
RCO 122.1R 117.4T (ELKINS RADIO)
CHARLESTON RCO 122.2 (ELKINS RADIO)
®CHARLESTON APP/DEP CON 119.2 (South) 124.1 (North) 128.5
CHARLESTON TOWER 125.7 GND CON 121.8 CLNC DEL 118.55
AIRSPACE: CLASS C svc ctc APP CON.
RADIO AIDS TO NAVIGATION: NOTAM FILE CRW.
CHARLESTON (H) (H) VOR/DME 117.4 HVQ Chan 121 N38°20.98′ W81°46.19′ 082° 8.5 NM to fld. 1099/3W.
VOR unusable:
185°–190°
240°–250°
DME unusable:
230°–240°
ILS/DME 110.3 I–HCV Chan 40 Rwy 05. Class IA. ILS unusable for coupled apch blw 1,300′ MSL.
ILS/DME 110.3 I–CRW Chan 40 Rwy 23. Class IB. Glideslope unusable byd 4° right of course. Glideslope unusable for autopilot coupled apch blw 1,700′ MSL.
